Miragrid 8XT Geogrid

Miragrid 8XT Geogrid - 12' x 200' Roll - TenCate

$1,534.61


FREE SHIPPING
SKU MIRAFI-8XT-12X200

Miragrid 8XT Geogrid - 12' x 200' Roll - TenCate

Model: 8XT-12X200
Brand: TenCate
Size: 12' x 200'
Square Feet / Roll: 2,400
Weight: 220 lbs
Geogrid Specifications:  Download Miragrid 8XT Specification Sheet


Looking for a smaller roll size? We offer retaining wall geogrid in both 4' and 6' widths in addition to 12'. View Selection >

View our Full Selection of Geogrid >

Do you need a written quote? Submit a quote request >

This fabric is produced in the state of Georgia, USA and can meet Build America / Buy America (BABA) requirements when requested. If ordering this fabric for a BABA project be sure to indicate that a BABA fabric is required in the “order message” field on the cart page.

NOTE: Mirafi branded products are ineligible for return or order cancellation once the order has been shipped. If you would like to purchase an equivalent fabric which is eligible to be returned with a standard restocking fee please give us a call at (800) 748-5647.


This Product is Stocked in the California and Georgia Distribution Centers Only.

FREE SHIPPING

 Require a written quote?
Request Online >

 Questions? Call (800) 748-5647

PRODUCT SUMMARY

  • High long-term design strengths (LTDS): Miragrid® geogrids have more than 220,000 hours of tension creep testing performed at an independent test laboratory.
  • Credible: Dependable long term strength assured.
  • Cost effective: Creep resistant polyester fibers provide higher allowable tensile strength, minimizing the required number of geogrid layers. Wide rolls significantly reducing placement time, lowering cost.
  • Light weight: Easy to handle and no sharp edges.
  • Flexible, tough: Minimizes movement of soil structure.
  • Strength: Miragrid® geogrids provide the widest strength range, and are the highest strength geogrid material in the market today.

TenCate Miragrid® XT uniaxial geogrids function for:
- Soil Reinforcement

YOUR TRUSTED
MIRAFI SUPPLIER

  • We are an authorized Mirafi / Tencate distributor.
  • We only sell genuine Mirafi geogrid. We never ship mislabeled overruns or "knock-offs".
  • You order Mirafi, we ship Mirafi. Even if a stock issue arises we never substitute for another brand without the customer's direct consent.
  • When you call, we answer. When you call Paramount Materials you get a live person quickly, ready to help with product or order questions. (M-F 5:00 am - 3:00 pm Pacific Time)

Fabric Shipping Time - Georgia Warehouse:

By default, Mirafi fabric orders ship from the Georgia warehouse where a full stock of the Mirafi fabric types are maintained. Most orders ship same day (M-F) if order is placed before 11:00 AM EST. Transit times displayed in the map are listed in business days, are approximate and are specific to the Mirafi fabric line. The day that the order is shipped is not counted as a transit day. Most Mirafi fabric rolls ship via LTL freight. For expedited shipping rates please call: (800) 748-5647

The transit times displayed on the map are for our free shipping option.

Fabric Shipping Time - Southern California Warehouse:

Note: By default, orders ship from the Georgia warehouse with the standard transit times shown above. If you would like your order to ship from the Southern California warehouse (Mira Loma) you must first fill out a stock check request. Orders can also be picked up at this warehouse location if preferred. Southern California warehouse orders must be placed over the phone.

Most Mirafi fabric California warehouse orders ship same day (M-F) if order is placed before 11:00 AM EST. Transit times displayed in the map are listed in business days, are approximate and are specific to the Mirafi fabric line. The day that the order is shipped is not counted as a transit day. Most Mirafi fabric rolls ship via LTL freight. For expedited shipping rates please call: (800) 748-5647

The transit times displayed on the map are for our free shipping option.

PRODUCT INFORMATION

TENCATE MIRAGRID® XT UNIAXIAL GEOGRIDS:

TenCate Miragrid® XT uniaxial geogrids are high performance woven polyester and polymer-coated geogrids used for soil reinforcement. TenCate Miragrid® XT uniaxial geogrids are used in Mechanically Stabilized Earth applications including internally reinforced walls, segmental retaining walls (SRW's), and steepend slopes. TenCate Miragrid® XT uniaxial geogrids provide high, long-term design strengths (LTDS) and excellent soil interaction. TenCate Miragrid® XT uniaxial geogrids are constructed of high tenacity, high molecular weight, woven polyester to deliver long-term performance.


The Difference TenCate Miragrid® XT uniaxial geogrids make:

- Flexible and durable
- Excellent creep resistance
- High long-term design strengths
- Lightweight and easily handled
- Cost effective
- Custom fabricated
- System Solutions:

Mechanically Stabilized Earth

- Steepened Slopes: Vegetated and Wrapped Faced
- Walls: Permanent and Temporary
- Segmented Retaining Walls
- Void Spanning
- Veneer Reinforcement
- Soil Reinforcement
- Landfills

Downloads:

 Product Description Sheet (MARV)

2XT Product Description Sheet

2XT Tri-fold

Engineered Structures Brochure

Mechanically Stabilized Earth Line Card

NTPEP Report REGEO-2011-01-001

NTPEP Report REGEO-2015-01-002



Technical Data Sheet PDF (MARV):



Case Studies:

Miragrdi 8XT Installed at Jobsite

Miragrid 8XT Geogrid Comes in Long Rolls

Miragrid 8XT – Case Study

The design for the new wine process facility required wastewater detention ponds the size of three football fields. The ponds would be constructed for containing and treating the dregs of the wine processing at the facility.  In order to comply with state requirements of water quality, the berms needed reinforcement to protect the ponds.

The Design

Originally, the design required the grid lengths to extend 27-feet outside the base of the berm and 10-feet into the pond area. There would have a significant overlapping on all corners of the ponds and considerably increase the necessary material using the specified geogrid.  Reed & Graham, Inc is the local distributor of TenCate® Geosynthetics. TenCate® gave technical help to the contractor and engineer on the project. Based on the requirements of the design, the contractor presented and was accepted by the engineer for TenCate Miragrid® 8XT geogrid as a working equivalent to the specified geogrid. The reason for the engineer's decision was based on the high tenacity polyester encapsulated in the PVC coating, offering a high strength geogrid with high durability and low creep features. The engineer decided that the features of  Miragrid® 8XT were perfect to provide high seismic resistance for the berms.

Construction

Teichert, Inc. decided buying the master rolls would save on both time and money.  Miragrid® 8XT's master rolls were precut to the needed lengths while a large bank of soil was in the process of being built. To reduce the waste of material they used longer lengths of master rolls. The 12-foot roll widths saved on overlaps at the corners, saving costs for the contractor and the owner of the project. Once they reached the elevations, the geogrid was rolled out by hand without using staples or pins to keep it in place. After the placement was completed, they resumed placing fill and compacting over the geogrid with conventional scrapers.  The procedure was performed for five layers and three ponds.

Performance

The high strength at low strain features of the TenCate Miragrid® geogrid made it a perfect choice for seismically stabilizing the berms. The wider and longer rolls helped prevent waste to a minimum and save on costs for both the owner and contractor.  The performance of the geogrid went beyond the expectations of the engineer and shortened the construction time of the project.
